Central Air Handling units

ATEX – FOR WHEN DANGER IS IN THE AIR

THE AIR HANDLING UNIT WITH DUAL ATEX CERTIFICATION

Air handling units installed in areas with potentially explosive atmospheres have to comply with ATEX directive 2014/34/EU. Maximum safety – thanks to TROX air handling units for potentially explosive atmospheres:

  • Developed especially for zone 1 and zone 2 areas with potentially explosive atmospheres
  • Meet the requirements for groups IIA and IIB of flammable gases and vapours, and temperature classes T1 to T4
  • Configurable air handling units
  • Integral ATEX-compliant components

We manufacture our X-CUBE Ex units in compliance with ISO IEC 80079-34.

And we don’t stop there: We also have conformity to our QM system tested and certified by an independent institute.

TROX is in fact the only manufacturer to offer this dual certification.

X-CUBE X2: STABLE AND SMART

IDEAL FOR SOLUTIONS UP TO 25,000 M³/H

The X-CUBE X2 is a newly developed series for small to medium volume flow rates, designed specifically by TROX to extend the X-CUBE range.

It provides low and medium volume flow rates, can be configured to virtually any application and comes with a range of new features. One new feature is the X-CUBE Configurator, a web-based tool that helps you with selecting and sizing air handling units.

THE HIGHLIGHTS AT A GLANCE

  1. • Freely configurable units and pre-configured compact solutions
  2. • Good mechanical strength of the unit base
  3. • Excellent hygiene properties thanks to smooth internal surfaces and small clearances
  4. • Intuitive operation and integration into building management systems using the control software X-CUBE control 2.0

CLASSES IN ACCORDANCE WITH EN 1886

  1. • Thermal transmittance class T2
  2. • Thermal bridging class TB2
  3. • Casing leakage L1
  4. • Stability D1

X-CUBE CROFCU

AIR DISTRIBUTION FOR CLEAN ROOMS. CLEVER AND FLEXIBLE.

The X-CUBE CROFCU is a compact ventilation unit that ensures and maintains the essential conditions for all classes of clean rooms. The secondary unit for use with centralized ventilation and air conditioning systems is typically installed in false ceilings. It dissipates high thermal loads and requires only a low fresh air volume flow. The primary air system (patent pending) allows for the direct removal of exhaust air while fresh air is supplied to the room.

  • Suitable for all clean room concepts
  • Pumped chilled water cooling system with room temperature control
  • Increased flexibility if several units are connected
  • Energy-efficient plug fan with EC motor
  • Addition of fresh air from 50 m3/h to 2000 m3/h
  • Monitoring of filters downstream
  • Control of airlocks for people and material
  • Contamination check by means of pressure zone control
  • Space-saving due to smaller ducts
  • Simple and quick commissioning due to plug and play

X-CUBE

THE NEW TROX AIR HANDLING UNITS

With the TROX X-CUBE, an air handling unit with unlimited configuration options, TROX sets a new standard in the AHU market and defines considerably higher levels of quality, performance, flexibility, reliability, energy efficiency, and hygiene. Compelling all down the line. TROX now offers everything from a single source: air handling units and components – ideally complementary to each other.



  • For even more energy efficiency and better quality with less coordination effort.
  • For the ventilation of rooms and entire buildings, for filtering, heating, and cooling the air, for heat recovery as well as for humidification and dehumidification, and for volume flow rates of up to 86,000 m³/h
  • Flexible frame construction, completely covered externally by thermally insulated panels or doors
  • Easy installation, maintenance and cleaning
  • Significantly reduced wiring workload due to flexible control and regulation based on fieldbus technology.
  • Special hygiene construction variant according to AHU Guideline 01 (RLT-Richtlinie 01) for use in hospitals and laboratories; weatherproof construction variant for outdoor installation

X-CUBE COMPACT

GROSSE LEISTUNG AUF KLEINEM RAUM – KOMPAKT.EFFIZIENT.TROX

Der X-CUBE compact zeichnet sich durch hohe Qualität bis ins Detail und viele intelligente Vorteile aus.

Mit dem X-CUBE compact steht eine anschlussfertige, vorkonfigurierte Lösung zur Verfügung,
die die herausragenden Qualitätsmerkmale der X-CUBE Technologie auf kleinstem Raum vereinigt.
Mit Volumenströmen von 600 bis 6.000 m³/h und Rückwärmzahlen von über 80 % (trocken nach
DIN EN 308) bieten diese Geräte die ideale Lösung für kleinere und mittelgroße Anwendungen.

Energieeffiziente, freilaufende Ventilatoren mit EC-Antrieb gewährleisten höchste Wirkungsgrade und niedrige Schallpegel. Umfangreiches Zubehör wie Nacherhitzer, CO2-Fühler oder ein Raumbediengerät kann problemlos an die X-CUBE compact Steuerung angeschlossen werden.

Vorteile auf einen Blick

  • Volumenströme von 600 bis 6.000 m³/h
  • Maximale Energieeffizienz
  • Leistungsfähige EC-Ventilatoren
  • Hoher Hygienestandard (VDI 6022 konform)
  • Wärmerückgewinnung mit Rotationswärmeübertrager oder
    Gegenstrom-Plattenwärmeübertrager (mit seitlichem Kondensatanschluss)
  • Luftfilterung mit TROX Mini Pleat- oder NanoWave-Filtern
  • Anschlussfertige Lieferung (Plug&Play)
  • Integrierte, busfähige MSR
  • Intuitive Bedienung
  • Direkte Integration in moderne Gebäudeleitsysteme
  • Optional wetterfeste Ausführung mit pulverbeschichtetem Metalldach für Gerät
    und Zubehör in RAL 7012 inklusive umlaufender Tropfkante
  • Optional 3-teilige Geräteausführung (Die Gerätelieferung erfolgt vormontiert und
    kann bauseits geteilt werden)
  • Optional Stellfüße für Innen- und Außenaufstellung
  • Made in Germany
